V joint Ceiling panels

PVCPLUS Ceiling panels

v Joint Ceiling panels

These products are designed as a ceiling panels with a V grove tongue and groove joint. These panels are Ideal in wet or dry environments for indoor and outdoor areas and available in four different surface finishing such as Satin white, Matt white, timber and various finishes and textures. The white finishes are UV oil treated for steady colour in long term

Advantages

Smart Tongue & groove system
Smart Tongue & groove system
Low Maintenance
Low Maintenance
Fast And easy to install
Fast And easy to install
Cost Effective
Cost Effective
AU/NZ Certified
AU/NZ Certified
Rated ( Group 1 )
Rated ( Group 1 )
Insect Proof
Insect Proof
Waterproof
Waterproof

PRODUCT RANGE

These panels come with a Standard length of 5800mm with the following dimensions

200mmx8mm ( Width X Thickness )

Finishes

400mmx8mm ( Width X Thickness )

Accessories

Technical & Downloads

Chemical composition

PVC resin and calcium carbonate

Surface Treatment & Colour

  Transfer printing and laminated with a UV resistant coating

•  Custom design and colors can be made for bulk orders

Applications

  • bathrooms
  • caravan interiors
  • portable homes
  •  offices,
  • marine applications
  • food processing areas
  •  pools
  • water treatment plants
  • residential ceilings
  • Animal Shelters

Installation method

Recommend Using combination of P16 adhesive silicon and button head screw with fixing clip. (refer to installation instruction)

Maximum span and bending radius

  • 600mm centers of two beams for the 5mm or 8mm panels & 800mm for the 10mm panels
  • 600mm Maximum bending radius (1200mm for the 400mm wide panels )

Environmental

•  PVC site cuttings and unused pieces can be collected and recycled.

•  Product may be recycled upon final disposal.

TESTS AND CERTIFICATIONS

Fire rating

1. Group 1 In accordance with Specification A2.4 of the Building Code of Australia (CSIRO AS/NZ 3837)

2. Group 1-S in accordance with ISO 5660 parts 1 &2 (NZBC Verification Method C/VM2 Appendix A)

Packaging, Handling, Protection and Delivery Instructions

•  DEKKOPLUS panels come delivered in carton and plastic shrink packaging, care should be taken when handling these panels since they are very flexible.

•  Each pack of product contains 10 panels ( 4 panels for the 400mm wide panels ) each pack weighs about 50 KG so for a safe work procedure it must be carried by two people. If a forklift is used, a solid board under the panels to support the full-length package is needed.

•  DO NOT keep the product outside the packaging in direct sunlight for too long or the sun might cause damage the surface finish. All the carton packaging is recyclable.

Warranty

Five years from product manufacturing defects.

Limitations

Not suitable for applications exposed to direct sunlight.

Installation guidelines

•  Use a steel blade on an angle grinder to cut the panels or use a drop / circular saw with an aluminum blade to get a nice clean cut.

•  Always use P16 glue with the mechanical fixings for a sound installation of the panels.It is highly recommended to wear your safety gears such as goggles and earplug when cutting the panels.

•  After completing the installation, simply remove all the protection films of the surface and wipe the dust to get the best look of the panels.

Maintenance and cleaning

Generally, DEKKOPLUS panels are maintenance free however if there is any dust or germ on the surface it can be wiped off by a damp cloth. Any oil product on the surface just add a small amount of standard detergent apply with cloth and then rinse.
